- Works with Hunter ICC2 and HCC Controllers, compatible with Centralus™ and Hydrawise® Irrigation Management Platforms
- Add up to 54 valves plus P/MV up to 2,000′ line of sight*
- License-free LoRa wireless connections direct to valve box — no copper field wiring required
- Wireless Solar Repeater (RPT) can extend or double ranges
- Seamless system expansion enables connection across hardscapes and other obstacles without wiring
- Combine with conventional ICM or EZDS Modules as needed (54 stations plus P/MV maximum per controller)
- Isolation from lightning or surge events in the field
- No field wires, wire breaks, or tracking
- No cutting into hardscape, plowing, boring, or lightning surge back to the controller
Wireless Valve Link
320,00 €
Enable convenient wireless valve control for ICC2 and HCC Controllers with the highly flexible and easy-to-install Wireless Valve Link.
Number of Stations 54 plus master valve
Type Controller accessory, wireless valve control
- Works with Hunter ICC2 and HCC Controllers and is compatible with Centralus™ and Hydrawise® Software
- Adds up to 54 valves (+P/MV) up to 2,000′ line-of-sight or more with a Repeater
- License-free LoRa Technology enables wireless communication directly to the valve box — no copper field wiring required
- Combines with conventional ICM or two-wire EZDS Modules for ultimate flexibility
Specifications
OPERATING SPECIFICATIONS
- Low-profile, waterproof valve box lid mount for field durability
- Requires 1½” diameter hole in valve box lid (hole saw supplied with WVOM)
- Two-way communications confirm field performance
- 900 MHz LoRa radio (North America only)
- 1-, 2-, and 4-station configurations to optimize field installations
- Operates Hunter DC-Latching Solenoids
- Maximum distance from WVL to solenoid: 100′ with 18 AWG wire
- One or two 9 VDC batteries per WVL
- Replace batteries once per season or year
- Solar recharging option with SP-WVL
- Built-in site survey and manual test functions
- Easy, free set up with Bluetooth app (iOS 9.0 or above, Android 5.0 or above)
Approvals
- WVL in-box control links: IP68 (submersible)
- RPT Wireless Solar Repeater: IP55 (outdoor)
- UL, cUL, FCC, CE, UKCA, RCM, ISED
- Warranty period: 2 years
Features
The Wireless Valve Link product family eliminates some of the biggest contractor costs in irrigation installations: copper wire and unnecessary excavation to connect or repair distant valves. Like decoders, it replaces commodity wire with Hunter ingenuity and provides an efficient alternative to activating irrigation valves. Once connected, wireless signals are immune to issues that commonly afflict wired systems, such as wire degradation and lightning damage.
With the Wireless Valve Link, you can add valves up to 2,000′ (or more with a Repeater)* without the need for new valve wiring. Often described as a wireless decoder system, the Wireless Valve Link provides a flexible solution for complex landscapes. Now it’s possible to cross concrete sidewalks and asphalt driveways wirelessly, saving time and money during installation.
This convenient and innovative wireless valve technology simplifies installation for landscapes of all sizes by eliminating the need to run costly field wires or cut into hardscape.
* Wireless range is subject to terrain, foliage, buildings, and other site factors. Consult product documentation before installing.
